Crop of a top-side photograph of a North American Nintendo 64 mainboard, revision NUS-CPU-03, showing the BU9480F audio DAC U1 and the AMP-NUS amplifier U2 with its silkscreened pin numbers (1, 7, 8 and 14), the electrolytics C24, C25, C26, C28, C33, C128 and C142, the 220 µF video capacitors C15 and C16, the encoder U5, the video DAC U4 and the 78M05 regulator U13.
Source
[edit | edit source].jpg&veaction=edit§ion=2){kind=link}
.jpg&action=edit§ion=2){kind=link}
Cropped from Nintendo-N64-Motherboard-Top.jpg on Wikimedia Commons (retrieved 2026-10-25).
Author
[edit | edit source].jpg&veaction=edit§ion=3){kind=link}
.jpg&action=edit§ion=3){kind=link}
Evan-Amos
Licence
[edit | edit source].jpg&veaction=edit§ion=4){kind=link}
.jpg&action=edit§ion=4){kind=link}
Public domain: released by the author on Wikimedia Commons (Template:PD-self on the Commons page).
