File:Nintendo 64 NUS-CPU-03 audio and video output section (Evan-Amos).jpg
Size of this preview: 334 × 600 pixels. Other resolution: 1,220 × 2,190 pixels.
Original file (1,220 × 2,190 pixels, file size: 687 KB, MIME type: image/jpeg)
Summary
[edit | edit source].jpg&veaction=edit§ion=1){kind=link}
.jpg&action=edit§ion=1){kind=link}
Crop of a top-side photograph of a North American Nintendo 64 mainboard, revision NUS-CPU-03, showing the audio and video output section: the multi-out connector P7, the 78M05 regulator U13 with its silkscreened VI (+12V) and VO (+5V) labels, the VDC-NUS video DAC U4, the ENC-NUS encoder U5, the BU9480F audio DAC U1, the AMP-NUS amplifier U2 and the electrolytics C15, C16, C24, C25, C26, C28, C33 and C142.
Source
[edit | edit source].jpg&veaction=edit§ion=2){kind=link}
.jpg&action=edit§ion=2){kind=link}
Cropped from Nintendo-N64-Motherboard-Top.jpg on Wikimedia Commons (retrieved 2026-10-25).
Author
[edit | edit source].jpg&veaction=edit§ion=3){kind=link}
.jpg&action=edit§ion=3){kind=link}
Evan-Amos
Licence
[edit | edit source].jpg&veaction=edit§ion=4){kind=link}
.jpg&action=edit§ion=4){kind=link}
Public domain: released by the author on Wikimedia Commons (Template:PD-self on the Commons page).
