Nintendo's drawing of the inside of the Nintendo 64 upper housing, showing how a chamber cover spring of the Game Pak slot door must sit between the edges of its notch. Rendered at 220 dpi from page 43 of the hosted manual.
Source
[edit | edit source].png&veaction=edit§ion=2){kind=link}
.png&action=edit§ion=2){kind=link}
Authorized Service Center Manual, Nintendo of America Field Service Dept., Revision June 2002, page 43. Hosted as File:Nintendo Authorized Service Center Manual June 2002.pdf; see Nintendo Authorized Service Center Manual (June 2002).
Author
[edit | edit source].png&veaction=edit§ion=3){kind=link}
.png&action=edit§ion=3){kind=link}
Nintendo of America
Licence
[edit | edit source].png&veaction=edit§ion=4){kind=link}
.png&action=edit§ion=4){kind=link}
Copyright Nintendo of America Inc. Manufacturer service material, hosted for preservation and repair reference with the source cited.
