Summary
[edit | edit source]
Figure from Nintendo service bulletin 91129 showing where electrical tape goes on the NES-CPU-06 board: two 10 x 19 mm pieces on the component side at locations 3 and 4, and one 45 x 19 mm piece on the solder side covering locations 1 and 2.
Source
[edit | edit source]
Cropped from File:Nintendo Service Bulletin 91129 NES-CPU-06 Shield Modification.pdf, rendered on 25 October 2026.
Author
[edit | edit source]
Nintendo of America Inc., Service Department.
Licence
[edit | edit source]
Copyright Nintendo of America Inc. Not freely licensed. Hosted for preservation and repair reference, with the source cited.
