File:Oscilloscope probe x10 with ground clip.jpg
Size of this preview: 800 × 534 pixels. Other resolution: 1,920 × 1,281 pixels.
Original file (1,920 × 1,281 pixels, file size: 203 KB, MIME type: image/jpeg)
Summary
[edit | edit source]
A standard 10:1 oscilloscope probe (Testec series MF, marked x10 and max. 600 Vp) with its BNC plug, the ground lead and crocodile clip, and the sprung hook cover removed to show the tip. Used on Continuity Testing and Signal Tracing.
Source
[edit | edit source]
Wikimedia Commons, File:Oszilloskop Tastkopf 10x IMGP3769 smial wp.jpg (retrieved 2026-10-25). Downscaled to 1920 px wide.
Author
[edit | edit source]
Smial (Wikimedia Commons user).
Licence
[edit | edit source]
Free Art License 1.3 (FAL), https://artlibre.org/licence/lal/en/ , as stated on Wikimedia Commons.
