File:PALM dataflow.gif
Summary
[edit | edit source]
Data-flow diagram of the IBM 5110 processor: read data register, storage address register, operation register, storage data register, ALU register, 8-bit ALU, control ROS and register file, with the oscillator and bus connections. 995 × 736 pixels. Used on IBM PALM processor.
Source
[edit | edit source]
http://computermuseum.informatik.uni-stuttgart.de/dev/ibm_5110/technik/en/images/datenfluss.gif, an image in the site's IBM 5110 section (same file size, 16,181 bytes; checked 2026-10-01).
Author
[edit | edit source]
Christian Corti, IBM 5110 pages of the Stuttgart Computer Museum (University of Stuttgart).
Licence
[edit | edit source]
Copyright Christian Corti. No licence is stated at the source. Hosted for reference with the source cited.
