Inside of a Panasonic FS-A1MK2 (FS-A1mkII) with the top cover removed. The main board is printed "(C) Matsushita 1987". The power supply section with its electrolytic capacitors and choke is at the upper left, below the aluminium heatsink; the green HIC-1 hybrid board (Mitsumi EMC-NX0039) sits under the heatsink; the cartridge connector is at the top right and the keyboard ribbon at the right. Some wires on the board are later additions (the uploader notes that a ROM has been removed).
Source
[edit | edit source]
MSX Resource Center wiki, file page https://www.msx.org/wiki/File:Panasonic_FS-A1mkII_inside.jpg, uploaded by Gdx on 12 August 2018 ("MSX2 Personal Computer FS-A1mkII [inside]"). Retrieved 2026-10-21.
Author
[edit | edit source]
Uploaded to the MSX Resource Center wiki by Gdx; the original photographer is not named there.
Licence
[edit | edit source]
No licence is stated on the source page; copyright remains with the photographer. Hosted for repair reference, with the source cited.
