Drawing of the Videopac G7200 with its numbered parts from the English instructions for use: 1 9-inch black and white monitor, 2 cartridge, 3 cartridge slot, 4 on/off switch, 5 contrast control, 6 volume control, 7 keyboard, 8 hand control connections, 9 hand control, 10 joystick, 11 action button, 12 brightness control, 13 loudspeaker, 14 mains flex, 15 DIN output socket, 16 slots for the C7010 chess module.
Source
[edit | edit source].png&veaction=edit§ion=2){kind=link}
.png&action=edit§ion=2){kind=link}
Rendered from page 2 of File:Philips Videopac G7200 Instructions for Use.pdf.
Author
[edit | edit source].png&veaction=edit§ion=3){kind=link}
.png&action=edit§ion=3){kind=link}
Philips
Licence
[edit | edit source].png&veaction=edit§ion=4){kind=link}
.png&action=edit§ion=4){kind=link}
Copyright Philips. Reproduced from the instructions for repair reference.
