File:Quadra 660AV Recap Guide.jpg
Size of this preview: 800 × 574 pixels. Other resolution: 2,048 × 1,470 pixels.
Original file (2,048 × 1,470 pixels, file size: 991 KB, MIME type: image/jpeg)
Summary
[edit | edit source]
Recap-a-Mac's capacitor location map for the Macintosh Centris 660AV / Quadra 660AV logic board, marking eleven 47 µF 16 V and one 10 µF 16 V surface-mount electrolytics.
Source
[edit | edit source]
Recap-a-Mac, https://recapamac.com.au/quadra-660av/; image file https://recapamac.com.au/wp-content/uploads/2020/03/quadra_660av_recap.jpg (byte-identical) (retrieved 2026-10-01).
