File:SGI IRIS IP2 board capacitor legend (schematic 5000-556).png
Size of this preview: 800 × 325 pixels. Other resolution: 1,658 × 673 pixels.
Original file (1,658 × 673 pixels, file size: 86 KB, MIME type: image/png)
Summary
[edit | edit source].png&veaction=edit§ion=1){kind=link}
.png&action=edit§ion=1){kind=link}
Part of the discrete component legend on sheet 1 of SGI's IP2 board schematic (5000-556 revision C, 1985): capacitors C1 to C21 with their values, diodes, LED array, crystals, DIP switches and the LTC-7P battery BT1. Rendered at 300 dpi and cropped. Used on the SGI IRIS 3000 Capacitor Replacement Guide.
Source
[edit | edit source].png&veaction=edit§ion=2){kind=link}
.png&action=edit§ion=2){kind=link}
File:SGI IRIS IP2 processor board schematic (5000-556).pdf, from bitsavers.org.
Author
[edit | edit source].png&veaction=edit§ion=3){kind=link}
.png&action=edit§ion=3){kind=link}
Silicon Graphics, Inc.
Licence
[edit | edit source].png&veaction=edit§ion=4){kind=link}
.png&action=edit§ion=4){kind=link}
Copyright Silicon Graphics, Inc. Hosted for preservation and repair reference, with the source cited.
