Figure 7-12, "Locating the Password Jumper", from Silicon Graphics' Indy Workstation Owner's Guide (007-9804-060), page 128, rendered from the PDF at 200 dpi and cropped. It shows the PROM password jumper on the system board beside the power supply cable connectors, with the SIMM sockets below.
Source
[edit | edit source].png&veaction=edit§ion=2){kind=link}
.png&action=edit§ion=2){kind=link}
File:SGI Indy Workstation Owner's Guide (007-9804-060).pdf, page 128.
Author
[edit | edit source].png&veaction=edit§ion=3){kind=link}
.png&action=edit§ion=3){kind=link}
Silicon Graphics, Inc.
Licence
[edit | edit source].png&veaction=edit§ion=4){kind=link}
.png&action=edit§ion=4){kind=link}
Copyright Silicon Graphics, Inc. Reproduced from the manufacturer's manual for repair reference, with the source cited.
