Two Personal IRIS power supply assemblies on their mounting brackets. Top: a Power-One PFC375-4000 supply fitted to the original bracket as a replacement. Bottom: an original L&H Research supply, showing its circuit board with the large input electrolytic capacitors, transformers and the output section.
Source
[edit | edit source].jpg&veaction=edit§ion=2){kind=link}
.jpg&action=edit§ion=2){kind=link}
Posted by jan-jaap in "Introducing: my Personal IRIS 4D/35", IRIX Network forum, 15 October 2019, forums.irixnet.org/thread-1468.html; image file jurassic.nl/external/20191011-pi/DSC_4481.jpg.
Author
[edit | edit source].jpg&veaction=edit§ion=3){kind=link}
.jpg&action=edit§ion=3){kind=link}
jan-jaap (IRIX Network forum)
Licence
[edit | edit source].jpg&veaction=edit§ion=4){kind=link}
.jpg&action=edit§ion=4){kind=link}
No licence stated by the photographer. Posted publicly on the IRIX Network forum; hosted for repair reference with the photographer credited and the source linked.
