File:SGI Visual Workstation 540 interior (Owner's Guide Figure 2-6).png

Labelled drawing of the inside of the Silicon Graphics 540 visual workstation with the side cover removed: power supply at the top left, the four DIMM slot groups, the primary processor and processor slots 1 to 3, the voltage regulator brackets above and below the processor cage, the battery, password jumper and processor speed jumpers, the three fans, the six PCI slots and the three SCSI drive bays. Figure 2-6 of SGI's Silicon Graphics 540 Visual Workstation Owner's Guide (007-3882-001, 1999), p. 23, rendered from the PDF at 200 dpi and cropped. See SGI Visual Workstation 540.

File:SGI Visual Workstation 540 Owner's Guide (007-3882-001).pdf, from https://techpubs.jurassic.nl/library/manuals/3000/007-3882-001/pdf/007-3882-001.pdf (retrieved 2026-10-21).

Silicon Graphics, Inc. (illustrated by Kwong Liew, as credited in the guide).

Copyright Silicon Graphics, Inc. Manufacturer documentation hosted for preservation and repair reference, with the source cited.
