File:SGI Visual Workstation 540 system board and power supply (sgistuff.net).jpg

Size of this preview: 800 × 531 pixels. Other resolution: 2,200 × 1,461 pixels.

Original file (2,200 × 1,461 pixels, file size: 635 KB, MIME type: image/jpeg)

Summary

Photograph of the inside of a Silicon Graphics 540 visual workstation with the side cover removed. The power supply label (upside down, top left) shows SGI part number 060-0048-001 and the DC output ratings. Below it are the DIMM slot groups, the upper voltage regulator connectors with a CR2032 cell above them, the processor cage with two Pentium III Xeon heatsinks, the two vertical fans at the right, and the lower regulator cards under the cage with rows of radial electrolytic capacitors and toroidal inductors. Downscaled to 2200 px wide. Used on SGI Visual Workstation 540 Capacitor Replacement Guide.

Source

sgistuff.net, Visual Workstation 320/540 page, "Closeup of the Xeon CPUs", http://sgistuff.net/hardware/systems/images/vw540-xeon-2400.jpg (retrieved 2026-10-21), from http://sgistuff.net/hardware/systems/vw320540.html.

Author

Gerhard Lenerz (sgistuff.net), photographed 13 December 2011 according to the image metadata.

Licence

No licence stated by the source. Copyright Gerhard Lenerz. Used, with credit, to show the hardware described on this wiki.
