File:SNES audio DAC and pre-amplifier (Donaldson redraw).png
Summary
[edit | edit source].png&veaction=edit§ion=1){kind=link}
.png&action=edit§ion=1){kind=link}
Crop of the audio DAC and pre-amplifier: U17, a uPD6376 16-bit stereo DAC (LOUT pin 11, ROUT pin 6, with C73 47 uF 10 V on the reference pins and C102 0.1 uF on the supply), feeding two LM324 sections, U100D (right, output pin 14) and U100C (left, output pin 8), through 22 k resistor and capacitor filters (R99, R101, R102, C74, C75, C76; R103, R104, R105, C77, C78, C79). U100D is drawn on the VS supply with C80 0.1 uF; R106 and R107 (5.1 k) load the outputs. From Jonathon W. Donaldson's community redraw of the NTSC Super NES main board (SNS-CPU-GPM-01/02 and SNS-CPU-RGB-01/02), revision 1.5, 24 February 2014. Not a Nintendo document.
Source
[edit | edit source].png&veaction=edit§ion=2){kind=link}
.png&action=edit§ion=2){kind=link}
Cropped from File:Snes schematic.pdf, described on SNES Schematic. Rendered at 600 dpi.
Author
[edit | edit source].png&veaction=edit§ion=3){kind=link}
.png&action=edit§ion=3){kind=link}
Jonathon W. Donaldson (redraw). The circuit is Nintendo's.
Licence
[edit | edit source].png&veaction=edit§ion=4){kind=link}
.png&action=edit§ion=4){kind=link}
No licence accompanies the drawing. Hosted for repair reference.
