Crop of a photograph of the circuit board of a Super NES controller, front side, removed from its case with the cord still attached. The board is printed "(C) 1990 Nintendo Co., Ltd.", "MITSUMI" and "56V313C 1992.01". It carries two 16-pin surface-mount ICs marked 4021BF, labelled ICA and ICB, resistors R1 to R15, capacitors C1 and C2, the five-pin cord connector CN1 (pins 5 and 1 marked), carbon contact areas for the direction pad, SELECT, START, A, B, X and Y, and the TL and TR shoulder contacts at the two ends.
Source
[edit | edit source].jpg&veaction=edit§ion=2){kind=link}
.jpg&action=edit§ion=2){kind=link}
Cropped from Nintendo NES and Super Nintendo controller PCBs.jpg on Wikimedia Commons (retrieved 2026-10-25), which shows an NES and a Super NES controller board side by side; this crop is the Super NES board. The Commons file records the photograph as first published on Flickr by the author.
Author
[edit | edit source].jpg&veaction=edit§ion=3){kind=link}
.jpg&action=edit§ion=3){kind=link}
Dennis van Zuijlekom.
Licence
[edit | edit source].jpg&veaction=edit§ion=4){kind=link}
.jpg&action=edit§ion=4){kind=link}
Creative Commons Attribution-ShareAlike 2.0, as stated on the Wikimedia Commons file page. This crop is released under the same licence.
