File:SNS-CPU-APU-01 62-pin connector solder joints (Evan-Amos).jpg
Size of this preview: 799 × 199 pixels. Other resolution: 2,135 × 532 pixels.
Original file (2,135 × 532 pixels, file size: 288 KB, MIME type: image/jpeg)
Summary
[edit | edit source].jpg&veaction=edit§ion=1){kind=link}
.jpg&action=edit§ion=1){kind=link}
Crop of the underside of a North American SNS-CPU-APU-01 Super NES main board, showing the 62 solder joints of the cartridge connector in two rows, with the silkscreen numbering 1 to 31 and 32 to 62. On this board the connector is soldered through the board.
Source
[edit | edit source].jpg&veaction=edit§ion=2){kind=link}
.jpg&action=edit§ion=2){kind=link}
Cropped from Nintendo-Super-NES-Mk1-Motherboard-Bottom.jpg on Wikimedia Commons (retrieved 2026-10-25).
Author
[edit | edit source].jpg&veaction=edit§ion=3){kind=link}
.jpg&action=edit§ion=3){kind=link}
Evan-Amos.
Licence
[edit | edit source].jpg&veaction=edit§ion=4){kind=link}
.jpg&action=edit§ion=4){kind=link}
Public domain, as released by the author on Wikimedia Commons.
