Crop of the top of a North American SNS-CPU-APU-01 Super NES main board around the Multi Out connector P4 (pins 1 to 12 marked on the board): the video encoder U7, marked S-RGB A and BA6596F; the audio chip U10, marked S-MIX A; the eight-pin U14, marked 6379A; capacitors C12, C13 (10 uF 16 V), C15 (47 uF 16 V), C16, C17 (33 uF 25 V), C18 and C19; and part of the expansion connector P5.
Source
[edit | edit source].jpg&veaction=edit§ion=2){kind=link}
.jpg&action=edit§ion=2){kind=link}
Cropped from Nintendo-Super-NES-Mk1-Motherboard-Top.jpg on Wikimedia Commons (retrieved 2026-10-25).
Author
[edit | edit source].jpg&veaction=edit§ion=3){kind=link}
.jpg&action=edit§ion=3){kind=link}
Evan-Amos.
Licence
[edit | edit source].jpg&veaction=edit§ion=4){kind=link}
.jpg&action=edit§ion=4){kind=link}
Public domain, as released by the author on Wikimedia Commons.
