File:Sanyo MPC-200 power supply area.jpg
Summary
[edit | edit source]
The power supply area of a Sanyo MPC-200, cropped from File:Sanyo MPC-200 inside.jpg: transformer PT0129, fuse F101 (T1A 250V), the two large electrolytic capacitors side by side next to a part on a black heatsink, and a column of four diodes below.
Source
[edit | edit source]
Cropped from the MSX Resource Center wiki file https://www.msx.org/wiki/File:Mpc200c_PCB.png (uploaded by Rderooy on 22 September 2016). Retrieved 2026-10-21.
Author
[edit | edit source]
Photograph uploaded to the MSX Resource Center wiki by Rderooy; the original photographer is not named there.
Licence
[edit | edit source]
No licence is stated on the source page; copyright remains with the photographer. Hosted for repair reference, with the source cited.
