File:Schematic Atari5200 4000.png

From RetroTechCollection
Original file (4,000 × 3,070 pixels, file size: 842 KB, MIME type: image/png)

Summary

[edit | edit source]

Atari's schematic of the Atari 5200 console board, 4000 pixels wide.

Source

[edit | edit source]

AtariAge schematics archive, https://www.atariage.com/5200/archives/schematics/ ; image file https://www.atariage.com/5200/archives/schematics/images/Schematic_Atari5200_4000.png (byte-identical) (retrieved 2026-10-01).

Author

[edit | edit source]

Atari, Inc. (the drawings). AtariAge credits the scans to the Bomarc Collection.

Licence

[edit | edit source]

Copyright Atari, Inc. Not freely licensed. Hosted for preservation and repair reference, with the source cited.
