Summary
[edit | edit source]
Sega Master System II main board, component side, with the cartridge connector, the two controller sockets at the front edge and the DC input. Downscaled to 2200 pixels wide from the Commons original.
Source
[edit | edit source]
Wikimedia Commons, File:Sega-Master-System-MkII-Black-Motherboard-1.jpg.
Author
[edit | edit source]
Evan-Amos
Licence
[edit | edit source]
Public domain, as released by the author on Wikimedia Commons.
