File:Sega 32X service bulletin 008 Mega Drive VA4 drawing.png
Size of this preview: 383 × 599 pixels. Other resolution: 1,304 × 2,038 pixels.
Original file (1,304 × 2,038 pixels, file size: 65 KB, MIME type: image/png)
Summary
[edit | edit source]
Drawing attached to Sega Quality Assurance Division service bulletin 008 (13 December 1994), "Sheet1": the front of the IC BD M5 PAL VA4 board around IC4, IC8, OSC1, FB6 and FB7 (steps 1 and 2: C92 and FB7), and two views of the back of the board showing C112 at C19 (step 3) and the ground jumper from C10 to the middle pin of EM16 (step 4).
Source
[edit | edit source]
Rendered at 200 dpi from page 2 of File:Sega 32X Service Builletins.pdf (see Sega 32X Service Bulletins).
Author
[edit | edit source]
Sega Enterprises, Ltd., Quality Assurance Division.
Licence
[edit | edit source]
Copyright Sega Enterprises, Ltd. Hosted for preservation and repair reference, with the source cited.
