Summary

Drawing attached to Sega Quality Assurance Division service bulletin 012 (28 March 1995): the rear (termination) side of the MD1 VA4 circuit board, with C100 and C78 marked "REMOVE".

Source

Rendered at 200 dpi from page 6 of File:Sega 32X Service Builletins.pdf (see Sega 32X Service Bulletins).

Author

Sega Enterprises, Ltd., Quality Assurance Division.

Licence

Copyright Sega Enterprises, Ltd. Hosted for preservation and repair reference, with the source cited.
