The power input corner of the export sub board 837-8953 ("IC BD MEGA-CD SUB BD EXPORT") in a Model 1 Sega CD, seen from above with the top case removed: transistor TR4, transistor TR3, fuse F1, diode D1, the DC jack CN2, the stereo mini jack CN3 and the Murata choke L2. Cropped from a photograph of the whole unit.
Source
[edit | edit source]
Cropped from File:Sega-CD-Base-Mk1-Inside.jpg on Wikimedia Commons (retrieved 2026-10-25).
Author
[edit | edit source]
Evan-Amos
Licence
[edit | edit source]
Public domain, as released by the author on Wikimedia Commons.
