A Sega Dreamcast Visual Memory Unit opened from the back. Left: the rear case half with the piezo buzzer disc glued inside and the CR2032 battery holder under its cover. Right: the solder side of the main board, showing the 14-pin connector, chip capacitors CE1 and CE2, the 32.768 kHz crystal X2, a 6.00 MHz ceramic resonator, the battery terminals BLADE-A and BLADE-B held by screws, and the buzzer leads soldered to the board.
Source
[edit | edit source]
GameTechWiki, https://www.gametechwiki.com/w/index.php/File:Dc-vmu-board-back.jpg (retrieved 2026-10-19). Used on GameTechWiki's VMU page.
Author
[edit | edit source]
Uploaded to GameTechWiki by user ITEM-3 (January 2014); the photograph's EXIF date is 9 June 2013.
Licence
[edit | edit source]
No licence is stated on the source page or by the site. Hosted here, credited to its source, to identify the board and its parts for repair reference.
