File:Sega Saturn HST-3200 with CD drive in place.jpg
Size of this preview: 789 × 600 pixels. Other resolution: 2,000 × 1,520 pixels.
Original file (2,000 × 1,520 pixels, file size: 416 KB, MIME type: image/jpeg)
Summary
[edit | edit source]
An original grey Japanese Sega Saturn (HST-3200, the first model) with the top case removed and the CD drive in place: the internal power supply board on the left, the CD drive in the middle and the shielding over the main board on the right. Downscaled to 2000 px wide from the Commons original.
Source
[edit | edit source]
File:Sega-Saturn-JP-Console-Mk1-Breakdown-02.jpg on Wikimedia Commons (retrieved 2026-10-25).
Author
[edit | edit source]
Evan-Amos
Licence
[edit | edit source]
Public domain, as released by the author on Wikimedia Commons.
File history
Click on a date/time to view the file as it appeared at that time.
| Date/Time | Thumbnail | Dimensions | User | Comment | |
|---|---|---|---|---|---|
| current | 10:53, 25 October 2026 | | 2,000 × 1,520 (416 KB) | Josh (talk | contribs) | Upload for repair guide |
You cannot overwrite this file.
File usage
The following page uses this file:
