Part of the "Parts and signal layout chart (main PWB)" in Sharp's PC-1350 service manual: C1 3.3 µF beside the BD1 diode, C2, C3 and C4 (1 µF each) by the R10 to R13 divider, C11, R1, R4 and the VR1 20 kΩ contrast control. Rendered at 300 dpi from the scan and cropped.
Source
[edit | edit source].png&veaction=edit§ion=2){kind=link}
.png&action=edit§ion=2){kind=link}
File:Sharp PC-1350 Service Manual.pdf, PDF page 17. The scan came from Sharp Pocket Computers (sharppocketcomputers.com), retrieved 2026-10-21.
Author
[edit | edit source].png&veaction=edit§ion=3){kind=link}
.png&action=edit§ion=3){kind=link}
Sharp Corporation.
Licence
[edit | edit source].png&veaction=edit§ion=4){kind=link}
.png&action=edit§ion=4){kind=link}
Copyright Sharp Corporation. Hosted for preservation and repair reference, with the source cited.
