Detail of the "PC-1500 Main P.W.B." drawing in Sharp's PC-1500 service manual (section 8, printed page 23): the 1SS98 and two 1S1588 diodes, the two 10 V 220 µF electrolytic capacitors between VGG and GND, and the row of pads for the Hi-MIC regulator module (pins 1 to 14). Rendered at 300 dpi from the scan and cropped.
Source
[edit | edit source].png&veaction=edit§ion=2){kind=link}
.png&action=edit§ion=2){kind=link}
File:Sharp PC-1500 Service Manual.pdf, PDF page 26. The scan came from Sharp Pocket Computers (sharppocketcomputers.com), retrieved 2026-10-21.
Author
[edit | edit source].png&veaction=edit§ion=3){kind=link}
.png&action=edit§ion=3){kind=link}
Sharp Corporation.
Licence
[edit | edit source].png&veaction=edit§ion=4){kind=link}
.png&action=edit§ion=4){kind=link}
Copyright Sharp Corporation. Hosted for preservation and repair reference, with the source cited.
