File:Sharp PC-1500 reset circuit (service manual).png
Size of this preview: 800 × 253 pixels. Other resolution: 944 × 298 pixels.
Original file (944 × 298 pixels, file size: 47 KB, MIME type: image/png)
Summary
[edit | edit source].png&veaction=edit§ion=1){kind=link}
.png&action=edit§ion=1){kind=link}
The power-on reset circuit from the "PC-1500 Main Circuit Diagram" in Sharp's PC-1500 service manual (section 9): a 50 V 1 µF capacitor from VCC into the TC50H001F Schmitt gate, and a second 50 V 1 µF capacitor on the output network that drives the I/O, CPU and µPD1990AC reset lines. Rendered at 300 dpi from the scan and cropped.
Source
[edit | edit source].png&veaction=edit§ion=2){kind=link}
.png&action=edit§ion=2){kind=link}
File:Sharp PC-1500 Service Manual.pdf, PDF page 28. The scan came from Sharp Pocket Computers (sharppocketcomputers.com), retrieved 2026-10-21.
Author
[edit | edit source].png&veaction=edit§ion=3){kind=link}
.png&action=edit§ion=3){kind=link}
Sharp Corporation.
Licence
[edit | edit source].png&veaction=edit§ion=4){kind=link}
.png&action=edit§ion=4){kind=link}
Copyright Sharp Corporation. Hosted for preservation and repair reference, with the source cited.
