File:Sharp X1 CZ-800CS main board.jpg
Summary
[edit | edit source]
Main board of a Sharp X1 (CZ-800CS), seen from above with the cassette deck (front) at the top and the rear connectors at the bottom. The photographer has labelled the Z80A CPU, the HD46505SP-2 CRT controller, the M80C49-22 sub-CPU and the AY-3-8910 sound generator. The power supply is in the perforated box on the left.
Source
[edit | edit source]
Photograph from the article "～ シャープ X1 ～ （レトロな○○ギャラリー）", AKIBA PC Hotline!, 26 February 2013: https://akiba-pc.watch.impress.co.jp/docs/column/retrohard/588974.html (retrieved 2026-10-21). Image URL: https://akiba-pc.watch.impress.co.jp/img/ah/docs/588/974/x14.jpg
Author
[edit | edit source]
後藤 儀兵衛 (Goto Gihei), for AKIBA PC Hotline!, Impress Watch Corporation.
Licence
[edit | edit source]
Copyright Impress Watch Corporation (2013). Not freely licensed. Used to identify the product and show its construction, with the source credited.
