File:Sony HB-10P main board.jpg
Size of this preview: 800 × 598 pixels. Other resolution: 1,024 × 765 pixels.
Original file (1,024 × 765 pixels, file size: 116 KB, MIME type: image/jpeg)
Summary
[edit | edit source]
The component side of the PU-37 main board in a Sony HB-10P, in the lower case with the keyboard ribbon cable attached at the left. The board in this photograph has extra wires added by a previous owner.
Source
[edit | edit source]
MSX Resource Center wiki, https://www.msx.org/wiki/File:Sony_HB-10P_PCB.jpg (retrieved 2026-10-21).
Author
[edit | edit source]
Uploaded to the MSX Resource Center wiki by Gdx on 5 June 2016; photographer not recorded.
Licence
[edit | edit source]
No licence is stated at the source. Used with credit to identify the board for repair reference.
