File:Sony HB-F700 PS-133 power supply schematic.png
Summary
[edit | edit source]
Power supply section of the Sony HB-F700 schematic: the PS-133 board, with the transformer T901, fuse F901 (T630 mA), line coil L901 and the power switch on the primary side, and three secondary circuits: +5 V through the D904 bridge, C909 (22000 uF 16 V) and IC902 (SI3052V); +12 V through D901 and D903, C905 (10000 uF 25 V) and IC901 (SI3122V); and -12 V through D902, C912 (470 uF 35 V) and IC903 (NJM79L12A). Cropped from printed page 40 of Sony's HB-F700P/F700S/F700F/F700D service manual, rendered at 400 dpi and reduced.
Source
[edit | edit source]
Cropped from File:Sony HB-F700 Service Manual.pdf, page 40 (MSX Archive scan by HansO, 2001).
Author
[edit | edit source]
Sony Corporation.
Licence
[edit | edit source]
Copyright Sony Corporation. Hosted for preservation and repair reference, with the source cited.
