Summary
[edit | edit source]
A 3D render of a "Switchless Kernal Switcher" adapter board for the Commodore 64: a 28-pin socket footprint with an 8-pin surface-mount chip (U2) and capacitor C1 inside it, and a six-pin header labelled GND, LED, EXR, RST, RES and VCC.
Source
[edit | edit source]
Source not recorded.
Author
[edit | edit source]
Not recorded.
Licence
[edit | edit source]
Not recorded.
