Tandy's exploded drawing of the Tandy 5000 MC system unit, labelling the top cover, 3.5-inch floppy disk drive, power switch arm, power supply assembly, main logic board, CPU logic board, memory logic board and the cover mounting screws.
Source
[edit | edit source].png&veaction=edit§ion=2){kind=link}
.png&action=edit§ion=2){kind=link}
https://www.ardent-tool.com/Tandy/5000MC_Exploded.gif (Ardent Tool of Capitalism, Tandy 5000 MC page; retrieved 2026-10-22). Converted from GIF to PNG.
Author
[edit | edit source].png&veaction=edit§ion=3){kind=link}
.png&action=edit§ion=3){kind=link}
Tandy Corporation (drawing); page maintained by Ardent Tool of Capitalism
Licence
[edit | edit source].png&veaction=edit§ion=4){kind=link}
.png&action=edit§ion=4){kind=link}
Copyright Tandy Corporation. Manufacturer's drawing, hosted for repair reference with the source cited.
