File:Twentieth Anniversary Macintosh umbilical connector coupling (Apple).png
Size of this preview: 800 × 377 pixels. Other resolution: 870 × 410 pixels.
Original file (870 × 410 pixels, file size: 114 KB, MIME type: image/png)
Summary
[edit | edit source].png&veaction=edit§ion=1){kind=link}
.png&action=edit§ion=1){kind=link}
Apple's photograph of the umbilical cable coupling between the Twentieth Anniversary Macintosh main unit and the bass unit, with the alignment bumps marked and the metal locking ring between them. From the Basics section, "Connecting the Base Unit to the Main Unit", p. 6 (PDF p. 8).
Source
[edit | edit source].png&veaction=edit§ion=2){kind=link}
.png&action=edit§ion=2){kind=link}
Apple Computer, Twentieth Anniversary Macintosh Service Source (1997), hosted here as File:Twentieth_anniversary_mac.pdf. Page rendered at 200 dpi and cropped to the figure (2026-10-02).
Author
[edit | edit source].png&veaction=edit§ion=3){kind=link}
.png&action=edit§ion=3){kind=link}
Apple Computer, Inc.
Licence
[edit | edit source].png&veaction=edit§ion=4){kind=link}
.png&action=edit§ion=4){kind=link}
Copyright Apple Computer, Inc. Hosted for preservation and repair reference, with the source cited.
