Size of this preview: 800 × 517 pixels. Other resolutions: 2,560 × 1,656 pixels | 5,096 × 3,296 pixels.
Original file (5,096 × 3,296 pixels, file size: 236 KB, MIME type: image/gif)
Summary
[edit | edit source]
Commodore Business Machines drawing 320033, revision P, Schematic, Display Circuit, for the Commodore PET 2001 display assembly; drawn May 1978, approved 29 June 1978. Monochrome scan, 5096 × 3296 pixels. Described on Video Board Schematic (Rev 3, 320033).
Source
[edit | edit source]
http://www.zimmers.net/anonftp/pub/cbm/schematics/computers/pet/2001/video-3.gif (same file size; checked 2026-10-01).
Author
[edit | edit source]
Commodore Business Machines, Inc.
Licence
[edit | edit source]
Copyright Commodore Business Machines, Inc. Not freely licensed. Hosted for preservation and repair reference.
File history
Click on a date/time to view the file as it appeared at that time.
| Date/Time | Thumbnail | Dimensions | User | Comment | |
|---|---|---|---|---|---|
| current | 15:37, 17 April 2025 | | 5,096 × 3,296 (236 KB) | Josh (talk | contribs) | File uploaded with MsUpload Category:Commodore_PET_2001_Schematics |
You cannot overwrite this file.
File usage
The following page uses this file:
