Component layout of the CPC464 cassette PCB (PCB301, MT0001A, with the volume/LED board PCB302, MS0005A), from page 7 of Amstrad's CPC464 service manual. It shows the positions and values of the 300-series parts, including all twelve of the cassette board's electrolytic capacitors (C301–C324). Rotated and cropped from the scan; the IC pinout drawings on the same page are omitted.
Source
[edit | edit source]
Amstrad Consumer Electronics plc, CPC464 Micro Computer / CTM640 Colour Monitor / GT64 Green Monitor Service Manual, p. 7 "CPC464 Cassette PCB". Rendered from File:Amstrad CPC464 Service Manual.pdf (described at Amstrad CPC 464 Service Manual), 2026-10-01.
Author
[edit | edit source]
Amstrad Consumer Electronics plc
Licence
[edit | edit source]
Copyright Amstrad. Reproduced from the service manual for preservation and repair reference.
