File:Casio PV-16 CPU board.jpg
Summary
[edit | edit source]
CPU board C2305-1 of a Casio PV-16, both sides: µPD780C-1 CPU, HN613256P D19 BASIC ROM and two µPD4168C-20 RAM chips, with 47 µF 6.3 WV electrolytic capacitors.
Source
[edit | edit source]
MSX Resource Center wiki, file page https://www.msx.org/wiki/File:Pv16k.jpg, current version uploaded by Gdx on 15 February 2016 with the description "MSX1 Personal computer PV-16 [CPU board]". Retrieved 2026-10-21.
Author
[edit | edit source]
Photograph uploaded to the MSX Resource Center wiki by Gdx; the original photographer is not named there.
Licence
[edit | edit source]
No licence is stated on the source page; copyright remains with the photographer. Hosted for repair reference, with the source cited.
