Close crop of the crystal X1 on the ZX Interface 1 issue 4 board Polaroid, rotated 180 degrees so the marking reads the right way up. The can is marked "80000" (no decimal point is visible in the photograph) and "TEC". Native resolution of the scan. Used on Sinclair ZX Interface 1.
Detail rendered from File:Ferranti Archives IF1-SIN-POL-009b Polaroid of a ZX Interface 1 issue 4 board, ULA and ROM end.pdf.
