File:Logic probe with TTL-CMOS and pulse-memory switches.jpg
Size of this preview: 800 × 311 pixels. Other resolution: 1,920 × 746 pixels.
Original file (1,920 × 746 pixels, file size: 199 KB, MIME type: image/jpeg)
Summary
[edit | edit source]
A hand-held logic probe for digital circuits: HI and LO lamps near the tip, a TTL/CMOS switch, a MEM/PULSE switch with a lamp between the switches, and a lead ending in red and black clips for the circuit's supply. Used on Logic Chip Testing.
Source
[edit | edit source]
Wikimedia Commons, File:Logicprobe chtaube070101.jpg (retrieved 2026-10-25). Downscaled to 1920 px wide.
Author
[edit | edit source]
Christian Taube.
Licence
[edit | edit source]
Creative Commons Attribution-ShareAlike 2.5 Generic (CC BY-SA 2.5), https://creativecommons.org/licenses/by-sa/2.5/
