Detail of Apple drawing 050-0159-A, Schematic, Mac+ Main Logic PCB (March 1986): the NCR 5380 SCSI controller U6A, the external DB-25 SCSI connector J3, and the diode CR1 (1N4001) drawn between +5VF and J3 pin 25, TPWR. The same drawing lists CR1 under "Not used" in its reference designation table.
Source
[edit | edit source].png&veaction=edit§ion=2){kind=link}
.png&action=edit§ion=2){kind=link}
Cropped from File:MacintoshPlus LogicBoard Shematic.jpg (region x 11400-13200, y 4700-6300 of the 13,200 × 10,200 scan).
Author
[edit | edit source].png&veaction=edit§ion=3){kind=link}
.png&action=edit§ion=3){kind=link}
Apple Computer, Inc.
Licence
[edit | edit source].png&veaction=edit§ion=4){kind=link}
.png&action=edit§ion=4){kind=link}
Copyright Apple Computer, Inc.; the sheet carries Apple's notice of proprietary property. Not freely licensed. Hosted for repair reference, with the source cited.
