File:Mattel Aquarius motherboard.jpg
Size of this preview: 800 × 522 pixels. Other resolution: 2,200 × 1,435 pixels.
Original file (2,200 × 1,435 pixels, file size: 470 KB, MIME type: image/jpeg)
Summary
[edit | edit source]
The Mattel Aquarius main board out of the case, component side, with the RF shield removed. The 10,000 µF axial capacitor and a Shoei 25 V radial capacitor are at the back left beside the power lead; the RF modulator can is behind the Ferranti REL-PLA2; the Z80-compatible NEC D780C-1 processor, an NEC D2364C-1 mask ROM, the TEA1002 colour encoder and the 44-way cartridge connector are on the right. Photographed in 2015.
