File:Mattel Aquarius with top case removed.jpg
Size of this preview: 800 × 419 pixels. Other resolution: 2,200 × 1,152 pixels.
Original file (2,200 × 1,152 pixels, file size: 218 KB, MIME type: image/jpeg)
Summary
[edit | edit source]
A Mattel Aquarius with the top case removed, showing the metal RF shield over the main board, the RF modulator can, the 10,000 µF and 25 V smoothing capacitors outside the shield, and the four-wire power lead entering at the back left. Photographed in 2015.
Source
[edit | edit source]
Wikimedia Commons, File:Mattel-Aquarius-Computer-Top-Removed-FL.jpg (retrieved 2026-10-19). Downscaled to 2200 pixels wide.
Author
[edit | edit source]
Evan-Amos
Licence
[edit | edit source]
Public domain (released into the public domain by the author)
