File:Mattel Baseball circuit boards, solder side.jpg
Size of this preview: 700 × 600 pixels. Other resolution: 2,200 × 1,885 pixels.
Original file (2,200 × 1,885 pixels, file size: 631 KB, MIME type: image/jpeg)
Summary
[edit | edit source]
Solder side of the same three Mattel Baseball boards: the main board marked 2942-9059 REV. B, the back of the LED display board marked NSA521 and KOREA, and the back of the key board.
Source
[edit | edit source]
Sean Riddle, "The First Mattel LED games", scan at https://www.seanriddle.com/rockwell/pcbscans/mattelbaseballpcbb.JPG (retrieved 2026-10-19). Downscaled.
Author
[edit | edit source]
Sean Riddle.
Licence
[edit | edit source]
No licence stated at the source; copyright Sean Riddle. Hosted for repair reference with credit to the author and a link to the source.
