Summary

ROM and RAM board of a National FS-5500, marked DFUP0039ZA. Labelled ROMs OS1 (DAS5500A1), HKN (DAS5500E1), AP1 (DAS5500C1), OS2 (DAS5500B1) and FDC (DAS5500F1), all marked 1985 Matsushita; two TMS4464-15NL DRAMs; 74LS-series logic; two radial electrolytic capacitors; edge connector CN201 along the bottom.

Source

MSX Resource Center wiki, File:National_FS-5500_ROM-Board-PCB.jpg, https://www.msx.org/wiki/File:National_FS-5500_ROM-Board-PCB.jpg (retrieved 2026-10-21). Uploaded there by Rderooy on 27 September 2016 with the description "National FS-5500 - ROM board PCB".

Author

The photographer is not recorded at the source.

Licence

No licence is stated at the source. Used here to show the board, with the source credited.
