Main board of a German-market Panasonic CF-2700, marked DFUP0007ZBJ-1 and "Copyright Matsushita Electric Ind. 1984". Visible: the supply regulator area at the top left with its large reservoir capacitors, a 4700 µF 16 V capacitor at the bottom left, the NEC D780C-1 CPU (IC8), the MN23257 BASIC ROM, the two cartridge connectors CN6 and CN7, the micro-switch connector CN5, two 64K × 4 DRAMs (HM50464P-15) at IC11 and IC12, two TMS4416 video RAMs at IC49 and IC50, and the TMS9929NL video chip (IC38) under a paper label.

Source

MSX Resource Center wiki, File:Cf2700geh.jpg, https://www.msx.org/wiki/File:Cf2700geh.jpg (retrieved 2026-10-21). Shown on the wiki page "Panasonic CF-2700 (GE)".

Author

Uploaded to the MSX Resource Center wiki by Mars2000you on 7 April 2020 with the description "Panasonic CF-2700 (GE) PCB". The photographer is not recorded.

Licence

No licence is stated at the source. Used here to identify the board revision, with the source credited.
