File:Panasonic FS-A1FX main board DFUP0250ZAU1a.jpg
Summary
[edit | edit source]
Main board of a Panasonic FS-A1FX out of the case, printed "DFUP0250ZAU1a COPYRIGHT MATSUSHITA ELECTRIC IND. 1988", photographed during a recap with the removed capacitors at the top left. The power supply is at the left, with its large reservoir capacitors and inductor; many outlined positions are empty. On the FS-A1FX the FM sound parts, the word processor SRAM and all but one ROM are not fitted (usbsecretbase.michikusa.jp, comparison of the FS-A1FX and FS-A1WX).
Source
[edit | edit source]
MSX Resource Center wiki, file page https://www.msx.org/wiki/File:Panasonic_FS-A1FX_PCB.jpg, uploaded by Gdx on 2 April 2016 ("MSX2p Personal Computer FS-A1FX [PCB]"). Retrieved 2026-10-21.
Author
[edit | edit source]
Uploaded to the MSX Resource Center wiki by Gdx; the original photographer is not named there.
Licence
[edit | edit source]
No licence is stated on the source page; copyright remains with the photographer. Hosted for repair reference, with the source cited.
