Photograph of a Silicon Graphics Indigo CPU board out of the machine, with SIMMs fitted, the CPU heat sink at upper left, the board's metal brackets and a cylindrical lithium cell wired to the board. The description on Commons does not say whether it is an IP12 (R3000) or IP20 (R4000) board. Downscaled for this wiki.
Source
[edit | edit source].jpg&veaction=edit§ion=2){kind=link}
.jpg&action=edit§ion=2){kind=link}
Wikimedia Commons, File:Sgi indigo mainboard.jpg (retrieved 2026-10-22).
Author
[edit | edit source].jpg&veaction=edit§ion=3){kind=link}
.jpg&action=edit§ion=3){kind=link}
ctvoigt
Licence
[edit | edit source].jpg&veaction=edit§ion=4){kind=link}
.jpg&action=edit§ion=4){kind=link}
Creative Commons Attribution-ShareAlike 3.0 Germany (CC BY-SA 3.0 DE), as stated on Commons.
