SGI Octane IP30 system board, part number 030-0887-003 revision F, component side. The eight DIMM sockets are at the left, the Dallas DS1687-5 real-time clock at the top left, the HEART and BRIDGE ASICs in the centre, and the audio circuitry with its surface-mount electrolytic capacitors at the upper right.
Source
[edit | edit source]
Wikimedia Commons, File:Silicon Graphics motherboard IP30 030-0887-003 REV F.jpg (retrieved 2026-10-21). Downscaled for upload.
Author
[edit | edit source]
Mister rf
Licence
[edit | edit source]
CC BY-SA 4.0, as stated on the Commons file page. Reuse must credit the author and keep the same licence where it is a ShareAlike licence.
