File:SGI Origin 2000 deskside MSC front panel.png
Size of this preview: 707 × 600 pixels. Other resolution: 1,333 × 1,131 pixels.
Original file (1,333 × 1,131 pixels, file size: 79 KB, MIME type: image/png)
Summary
[edit | edit source]
Line drawing of the Origin 2000 deskside module system controller (MSC) panel: reset and NMI switches, AC OK, DC OK, fan high-speed and over-temperature LEDs, eight-character display, security key switch with its Standby, On and Diagnostic positions, and the 8-pin mini-DIN diagnostic port.
Source
[edit | edit source]
Rendered from SGI, Origin2000 Deskside Owner's Guide, 007-3453-002, p. 39, Figure 3-5 (File:SGI Origin2000 Deskside Owner's Guide (007-3453-002).pdf), 2026-10-21.
Author
[edit | edit source]
Silicon Graphics, Inc.
Licence
[edit | edit source]
Copyright Silicon Graphics, Inc. Hosted for preservation and repair reference, with the source cited.
